S8 Series LED Light Bar

Baja Designs

Product Sku: 701013

  • $329.00

Select your options

Length
Beam Pattern
Lens Color
Orange
White

Baja Designs' latest LED light bar comes with a few new perks! Enjoy the clean aluminum frame with 6,350 lumens per 10" section, low amp draw of 4 amps per 10" section, and nearly 50,000 hours of LED life. The S8 also features upgraded reflectors, an amber backlit feature, and new scalloped housing design. The S8 is backed by Baja Designs' 30 Day Satisfaction Guarantee and Limited Lifetime Warranty giving you the ultimate in purchase protection!

Available Light Patterns:

  • Driving/Combo:  Maximum trail coverage in a single light.  The Driving/Combo pattern is equipped with both Driving (42°) and spot (9°) optics to provide you with a smooth blend of light for both near field applications and distance
  • Wide Driving: BD was the first to develop a pattern specifically for cornering, dust and/or fog conditions. The Wide Driving pattern offers a 42° flattened horizontal beam for the ultimate in comfort lighting
  • Spot: A longer and narrower 9° beam focus for illumination further down the trail or road.  The Spot pattern is designed to be used in conjunction with additional Wide Driving and/or Driving/Combo beam lights
  • Work/Scene: Excellent work light or “scene light” with an extremely smooth 120° circle that projects about 40ft.  This pattern is not suitable for driving

Baja Designs Features:

  • Satisfactions Guarantee 30 Day Money Back Guarantee
  • Limited Lifetime Warranty Complete Purchase Protection
  • uService Replaceable Lenses And Optics
  • ClearView All The Light, Right Where You Need It.
  • MoistureBlock Waterproof, Rain Proof, Submersible
  • CopperDrive Only LED Driven At 100 percent
  • 5000K Daylight Less Driver Fatigue, Natural Color

Specifications:

  • LED Life Expectancy: 49,930 Hours
  • Front Lens: Hard Coated Polycarbonate
  • Housing: Aircraft Grade Aluminum w/Mil-Spec Hard Anodize
  • Bezel: Billet Machined Aluminum
  • Hardware and Bracket Material: Stainless Steel
  • Exceeds MIL-STD810G (Mil-Spec Testing)
  • Built-In Overvoltage Protection
  • IP69K (Waterproof up to 9ft and Pressure Washable)
  • IK10 Compliant (Mechanical Impact Testing)

Output/Draw specifications for different lengths:

  • 10"
    • Lumens - 6,350
    • Power Draw - 60W / 4.00A
  • 20"
    • Lumens - 12,700
    • Power Draw - 120W / 8.00A
  • 30"
    • Lumens - 19,050
    • Power Draw - 180W / 12A
  • 40"
    • Lumens - 25,400
    • Power Draw - 240W / 16A
  • 50"
    • Lumens - 31,750
    • Power Draw - 300W / 28A

Includes:
LED Light Bar
Mounting Brackets
